Place of Origin:
made in China
Brand Name:
ABB-460/660
Certification:
CE,CO,ISO
Model Number:
460/660
Automatic Palletizer Robotic Palletizer
IRB 460/ 660 is ABB Robotic’s latest generation of 4-axis palletizing robot, designed with a focus on its high production capacity, short cycle time at a high payload, long reach together with the very high uptime, which is significant for ABB’s robots. It comes in two versions; a handling capacity of 180 kg and 250 kg, both with a reach of 3.15 m. Customer connections as power, signals, Bus signals, and twin air are integrated into the robot, from the robot base to connections at the robot tool flange. The robot is equipped with the IRC5 controller and robot control software. Robot Ware supports every aspect of the robot system, such as motion control, development, and execution of application programs, communication, etc.
Technical Parameters
| ABB 460 | ABB 660 | ||
| 1 | Handling capacity | 110KG MAX | 180KG |
| Axis | 4 axis | 4 axis | |
| 2 | Reach | 2.4m | 3.15m |
| Weight | 925KG | 1650KG | |
| 3 | Power Consumption | 3.67KW | 0.61-3.17KW (depends on speed) |
| 4 | Manipulator during operation |
-25°C~ 55°C
|
-25°C~ 55°C
|
| 5 | Mounting | Floor-mounted manipulator | Floor-mounted manipulator |
| 6 | External Dimension | L1000×W1000×H1800mm | L 2821×W1196×H2882mm |
| 7 | Machine Color | White Color | White Color |
| 8 | Power Source | AC 220V 50HZ | AC 220V 50HZ, IP67 |
| 9 | Ground Level (3) | Minimum thickness of the concrete: 250mm | Minimum thickness of the concrete: 250mm |
| 10 | Safety Level | IP67 | IP67 |
