5-200g fully Automatic Horizontal Packaging Machinery 60pouches min

Product Details:
Place of Origin: CHINA
Brand Name: JINWANG
Certification: CE,ISO9001,ISO18000,ISO14000
Model Number: DXD-180F
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: wooden cases
Delivery Time: 15-90 work days
Payment Terms: L/C, T/T
Supply Ability: 1 Osets per month
Specifications Product Description Request A Quote
Specifications
Specifications
Name: DXD-180F Automatic Horizontal Pouch Packing Machine
The Material Of Frame: SS304
Film Roll Inner Diameter: Φ70-80mm
Film Roll External Diameter: Φ500mm
Power Source: Three Phase, AC380V, 50HZ
Power: 5.5KW
Filling Precision: 1%
Capacity: ≤60 Pouches/minute (Single Bag), ≤120 Pouches/minute (Double Bags)
High Light:

Horizontal Packaging Machine 60pouches Min

,

automatic horizontal packaging machinery

,

auto horizontal packing machine 60pouches Min

Product Description

5-200g DXD-180F Automatic Horizontal Pouch Packing Machine



1. Introduction:

DXD-180F Automatic Horizontal Pouch Packing Machine contains motor film-releasing, film forming, bottom sealing, vertical sealing, cutting, filling, pouch transferring and top sealing. The cams on the main shaft finish the coordinated action driven by the motor and the encoder on the main shaft feedback the position single. Under the control of the PLC, it realizes the function of film roll→film forming→film in-shape→powder filling→sealing→ finished products transferring. At last, the finished products enter the counting device, and then manually put them in boxes or cartons. The machine designs properly with a beautiful appearance. It adapts standard stripe sealing. It can realize automatic power, granule, SC, EC, AS filling with changing the filling device. The organic glass cover can prevent the flowing of dust which is more environmental-friendly



2.Main Technical Parameter

1 Capacity ≤60 pouches/minute (Single Bag), ≤120 pouches/minute (Double Bags)
2 Applicable Pouch Size

Single Bag: 80*100mm (Minimum), 180*225mm (Maximum)

Double Bag: (60+60)*70mm (Minimum), (90+90)*220mm (Maximum)

3 Packing Volume 200ml (Single Bag), 300ml (Double Bag)
4 Filling Precision ±1%
5 Film Roll Inner Diameter

Φ70-80mm



6 Film Roll External Diameter Φ500mm
7 Power Source Three Phase, AC380V, 50HZ
8 Power: 5.5KW
9 External Dimension:

3850×1000×1550mm (Dusting Pipe+60) (L*W*H)



10 Weight 2250KG



3. Allocations

NO. Name Brand Remarks
1 Inverter Schneider
2 PLC Schneider
3 Servo Drive Schneider
4 Servo Motor Schneider
5 Power Switch Schneider
6 Fan Sunon
7 Color Sensor Sunx
8 Proximity Switch Autonics
9 Encoder Omron
10 Vacuum Generator SMC
11 Contactor Schneider
12 Thermal Relay Schneider
13 Circuit Breaker Schneider
