Product Details:
|
|
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | JINWANG |
| Certification: | CE,ISO9001,ISO14000, ISO18000 |
| Model Number: | GD6-300 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Packaging Details: | wooden cases |
| Delivery Time: | 15-90 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1 Osets per month |
100-1000g Powder. GD6-300 Automatic Rotary Pouch Packing Machine
1. Introduction
The machine is making up with the automatic packing machine and filling system. It has wide application range and can pack liquid, powder, granule and solid products by changing different dosing system. The machine can change different packing volume in short period of time. The auto pouch feeding width can be adjusted by the handle. The machine is with inspecting device to make sure no fill and seal if the pouch is not opened successfully. This will save the pouch and products.
2. Main Technical Parameters
| 1 | Model | GD6-300 |
| 2 | Pouch Material | Complex film |
| 3 | Pouch Size: Width | 160-300mm, Length: 100-400mm |
| 4 | Packing Speed | 15-35 pouches/min |
| 5 | Pouch Feeding | Horizontal Feeding |
| 6 | Sealing Type | Single Sealing |
| 7 | Power Source | Three Phase, 380V, 50/60HZ |
| 8 | Weight | 1500KG |
| 9 | External Dimension | 1900*1700*1600mm (L*W*H) |
3. Allocations
| 1 | Touch Screen | Weiview | |
| 2 | Inverter | Omron | |
| 3 | PLC | Omron | |
| 4 | Connector | Schneider | |
| 5 | Button | Schneider | |
| 6 | Solenoid Valve | MAC | |
| 7 | Cylinder | SMC |
