Product Details:
|
|
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | JINWANG |
| Certification: | CE, ISO9001,ISO18000,ISO14000 |
| Model Number: | TN_150AS |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Packaging Details: | wooden cases |
| Delivery Time: | 15-90 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1 Osets per month |
50-1000ml Round bottle TN-150AS Automatic Self Adhesive Labeling Machine
1. Introduction:
TN-150AS Intellectual Labeling Machine is controlled by the PLC, HMI and servo drive labeling. The machine is easy to operate and has helping function and fault indication function. It is suitable for the self-adhesive labeling of round bottles
2. Main Technical Parameters:
| 1 | Applicable Bottle Diameter | Φ35-95mm |
| 2 | Label Height | 20-140mm |
| 3 | Label Length | 50-320mm |
| 4 | Labeling Precision | ±1mm |
| 5 | Capacity | ≤6500 Bottles/min |
| 6 | Power Source | ～220V, 50HZ |
| 7 | Power | 2.2KW |
| 8 | Weight | About 350kg |
| 9 | External Dimension | 2500×1000×1700mm (L×W×H) |
3. Allocations:
| No | Name | Brand | Remark |
| 1 | PLC | Schneider | |
| 2 | Touch Screen | Schneider | |
| 3 | Inverter | Schneider | |
| 4 | Servo System | Schneider | |
| 5 | Sensor | Sick | |
| 6 | Power Switch | Schneider | |
| 7 | Button | Schneider |
