Place of Origin:
made in China
Brand Name:
JWIM
Certification:
CE,CO,ISO
Model Number:
CZ-4B
Weighing-Type Fully Automatic Filling Machine Linear Scale Table Chain Pushtter Weighing Control Instrument
CZ-4B weighing-type fully automatic filling machine
General information:
CZ-4B weighing automatic filling machine consists of linear scale table (with roller path) and chain pushtter
Structure, fast, slow filling (with motor diving) mechanism, feed transition box, weighing control instrument and programmable control unit. The liquid filling scale can meet the needs of automatic weighing and filling of foam.
Suitable for materials
It is widely used in 5-30L barrels of automatic weighing and filling in pesticides, fine chemical, daily chemical, fertilizer, oil and other industries.
Technical parameters:
| 1 | Fill speed | ≤ 200 barrel / h (20Kg) (with water as the medium) |
| 2 | Measurement accuracy | ± 0.2% (Water as the medium) |
| 3 | Bottle type | Minimum. 200 × 140 × 320mm Max. 290 × 260 × 400mm (L × W × H) |
| 4 | Fill range | 5-30Kg. |
| 5 | Feed pipe diameter | DN40. |
| 6 | Feed port height | 2980mm. |
| 7 | Air source pressure | 0.6-0.8MPa. |
| 8 | Power Supply / Power | ~380V 50Hz/1.6KW. |
| 9 | Overall dimensions | 2138 × 1363 × 3140mm (L × W × H) |
| 10 | Weight | About 1,200 Kg |
Equipment dimension drawing:
Equipment advantages:
1, high accuracy: using the weighing filling system (Mettler-Toledo METTLER TOLEDO weighing sensor) to ensure the high accuracy of filling measurement. Use a unique ball walking bottle way to ensure a smooth bottle exit after filling.
2, uses fast and slow filling valve motor filling under the diving liquid surface, effectively solving the problem of material foam.
The 3, electric control system adopts French Schneider configuration, integrated electric control system, more stable, reliable, safe and low energy consumption..
4, has an independent cylinder-controlled residual droplet collection tank under the filling head, tetrafluoride external blocking plug, to ensure that the material does not leak outside the bottle mouth after the filling head is closed.
5, machine adopts high quality SUS304 stainless steel, tempered glass door cover to better adapt to various production environment, good anti-corrosion performance and easy cleaning. The sealing material of the material is PTFE.
6, host has its own cache box, equipped with material level detection system to automatically coordinate the feeding.
Main configuration of the equipment:
| No ial |
First name "Said that." |
Brand name |
| 1 | Weing sensor |
METTLER TOLEDO. Mettololedo |
| 2 |
Programmable controller CPU. |
Schneider. Schneider |
| 3 | Touch-screen |
Schneider. Schneider |
| 4 | Converconverter |
Schneider. Schneider |
| 5 | Count photoelectric |
SICK. Schker |
| 6 | Close proximity switch |
Leuze. Labor measurement |
| 7 | Switch on the power supply |
Schneider. Schneider |
| 8 | Pressure switch | SMC. |
| 9 | Cylinder |
FTEC. Eptai |
| 10 | Solenoid valve |
FTEC. Eptai |
| 11 | Button |
Schneider. Schneider |
| 12 | Warning lamp |
Schneider. Schneider |
| 13 | Circuit breaker |
Schneider. Schneider |
