3KW Automatic Powder Packaging And Sealing Equipment

Product Details:
Place of Origin: CHN
Brand Name: JWIM
Certification: CE ISO
Model Number: GD8-200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: wooden cases
Delivery Time: 15-90 work days
Payment Terms: L/C, T/T
Supply Ability: 1 Osets per month
Specifications Product Description Request A Quote
Name: GD8-200
Production Capacity: 20-40 Package / Sub-Sub * Actual Capacity Depends On The Packaging Material
Bag Bag Size: W100-210mm L100-350mm.
Suitable For The Bag Type: Flat Bag, Independent Bag * Zip Bags Require Custom M And Back Cover Bags Tested
Fill Accuracy: ± 1% (depending On The Material Condition)
Packaging Capacity: The ≤ 1000g * Is Determined By The Material Weight And Package Size
Power Supply / Power: Three-phase AC380V 50Hz/3KW.
Air Source Pressure: 0.5-0.7MPa.
Equipment Dimensions: 1970 × 1978 × 1610mm (L × W × H)
Complete Machine Weight: Approximately 1,600 Kg
High Light:

Automatic Powder Packaging And Sealing Equipment


3KW Powder Packaging And Sealing Equipment


powder packing and sealing machines

Product Description

The GD8-200 returns to the bag packing machine

General information:

The machine is a rotary structure, eight positions, a wide range of packaging, can package liquid, powder, particles, solid materials, only need to choose different metering and filling devices according to different materials. The equipment can quickly change the bag specifications, and the width of the automatic bag device can be easily adjusted by adjusting the handle; the standard detection equipment can detect that the machine without the packing device and the bag is not opened, so as to avoid waste of packing materials and raw materials.

3KW Automatic Powder Packaging And Sealing Equipment 0


Technical parameters:


1 Production capacity 20-40 Package / Sub-Sub * Actual capacity depends on the packaging material
2 Bag bag size W100-210mm L100-350mm.
3 Suitable for the bag type

Flat bag, independent bag

* Zip bags require custom M and back cover bags tested

4 Packaging capacity The ≤ 1000g * is determined by the material weight and package size
5 Fill accuracy ± 1% (depending on the material condition)
6 Power Supply / Power Three-phase AC380V 50Hz/3KW.
7 Air source pressure 0.5-0.7MPa.
8 Equipment dimensions 1970 × 1978 × 1610mm (L × W × H)
9 Complete machine weight Approximately 1,600 Kg


Equipment dimension drawing:

3KW Automatic Powder Packaging And Sealing Equipment 1

Equipment advantages:

1,The integrated design of whole machine replaces the traditional manual packaging, realizes the automation of product packaging and production, improves the production efficiency, and greatly reduces the product cost. The complete set of equipment can be operated alone by one person, greatly reducing the labor cost.

3KW Automatic Powder Packaging And Sealing Equipment 2

2, based on the years of experience, using a stable process and driving structure to ensure the packaging effect.

3KW Automatic Powder Packaging And Sealing Equipment 3

3, adopts the secondary filling mode, the first time for the large dose preliminary filling, to ensure the speed of the whole machine; the second filling with the American Metletoli multiple weighing sensor weighing and filling, to ensure the filling accuracy. (This function is optional)

3KW Automatic Powder Packaging And Sealing Equipment 4

4, adds the vibrator at the characteristics of the powder, which is more smooth without blocking. Fill the bottom solid mechanism, the bag material is more substantial.

3KW Automatic Powder Packaging And Sealing Equipment 5

5,Drop material detection device. No bags without falling materials, empty bags are not sealed, to reduce the waste of materials and materials and polluting equipment.

3KW Automatic Powder Packaging And Sealing Equipment 6

6, equipment reserved station, optional ribbon code der. (This feature is optional)

3KW Automatic Powder Packaging And Sealing Equipment 7

7, equipment is equipped with dust removal pipeline to connect with engineering exhaust system to reduce dust on production site. (This function is optional)

3KW Automatic Powder Packaging And Sealing Equipment 8

8,The electric control system adopts French Schneider configuration, with integrated electric control system, which is more stable, reliable, safe, green and low energy consumption.

3KW Automatic Powder Packaging And Sealing Equipment 9

9, packaging counter is of food grade 304 stainless steel, 2mm, mirror plate and electrical box is 304 stainless steel 2mm.Upper bag, open bag, sealing and clamping are of 304 stainless steel.

10,The drive part cam is 45 # forging material, heat treatment hardness ≥ HR50 degree, 45 # grinding shaft, smooth surface and wear resistance.

11, machine is standard equipped with automatic monitoring system device, can detect air pressure, temperature controller failure, bag mouth opening, to judge the state of the machine, can control the code playing device, filling device, filling device, heat sealing device, whether to move, so as to avoid waste of packaging materials and raw materials, and save production cost.

Main configuration of the equipment:


No ial First name "Said that." Product Card



Programmable controller




2 Touch-screen



3 Converconverter






Servo system



5 Vacuum pump


Baker, Germany

6 Solenoid valve SMC.
7 Cylinder SMC.
8 Button



9 Circuit breaker
